Timber Roof Panels & Trusses
system:
Timber frame
client:
Offsite manufacturer
scope:
Layouts, cut lists
project type:
Roof panels & trusses
standards:
Factory's own
delivered as:
Production pack
Roof cassettes and truss layouts documented for a timber frame line, coordinated with the walls below so every bearing and connection is resolved before production.
What the pack includes
Roof panels, trusses and bracing are modelled with the walls they sit on, so bearings, overhangs and openings are checked in the model, not on site.
Layouts
trusses & cassettes
Cut lists
from the model
Bracing
called up
Bearings
coordinated
The result
A roof pack that matched the walls first time, with no questions left for the floor.
