Timber Frame / Wood Framing
Panel drawings your framing line can build from, first time.
We document timber frame for factories in the UK, Europe, North America and Australia, whether you ship 2D panels (open or closed walls, floor cassettes and roofs) or complete 3D volumetric modules. Drawn to your line’s standards, with cut lists straight from the model.
Every decision is made in the model at LOD 400, so the factory floor is where you build, not where you think.
Every element your line produces.
- Wall panels, open or closed, with openings, headers (lintels) and sheathing.
- Floor cassettes and joist layouts.
- Roof panels and trusses.
- Full modules, where panels, cassettes and services come together.
- Fixings, connectors and hold-downs.
Each element comes with its elevation, cut list, material schedule and layout position, straight from the model.
Modeled once. Everything else follows.
We frame every panel in Revit using AGACAD, so the drawings, schedules and cut lists all come from one model, never redrawn by hand.
01.
Framing from your rules
Panel framing is generated from your rules (stud spacing, plate sizes, openings), so it stays consistent across the job.
02.
Schedules that follow the design
Cut lists and material schedules update automatically when the design changes.
03.
Native model handover
The native model is handed over, so your team or your machinery software can take it further.
Change the design, and the whole pack updates with it.
Your standards, built into the template.
Before the first project, we capture how your factory works, and every job after runs on it.
Job fifty looks exactly like job one.
See our timber panel work.
Years of experience running the drawing office for modular builders: dedicated modelers, one system, every project.
Panels or modules, your timber line gets the same system every time.
Also running a light gauge steel line? See how we document LGS →
